These amplifiers are designed for PA systems with applications such as announcement, intercommunication, background music and broadcasting in convention-halls, shopping centers, dining rooms, auditoriums and recreation areas. These desk top amplifiers have an integrated protective circuit to withstand overload or short-circuits of output. This results in very high reliability and easy installations without extra audio processors. It is a complete range from simple amplifiers till matrix amplifiers with built-in tuner and media player.
Specifications
UscitePotenza: 30W
Zone: 1
100V & 8Ohm: Morsetti
Uscita di linea: XLR
Loop through: RCA
Cuffie: Jack da 6,3mm
Ingressi
2x Mic/Linea: XLR/Jack combo & morsetti
1x Linea: RCA
Ingresso anteriore: Jack da 3,5mm
Lettore multimediale
Sorgente: USB di tipo A
File supportati: MP3, Wav
Formato: FAT32 fino a 32Gb
Riproduzione: Programma, Ripeti, Continuo
Sintonizzatore
Banda FM: 87,5 – 108 MHz
Preset: 10
Antenna: 75Ohm
Caratteristiche
Filtro parlato: -3dB, 300Hz 6db/oct
Alimentazione phantom: 18V
Controllo tono: Bassi 100 Hz, alti 12 KHz, +/-12dB
Alimentazione
generale: 230V AC
Alimentazione di back-up: CC 24V
Consumo di corrente: 80W
Connessione di corrente: Dimensioni
IEC: 270x262x88mm (LxPxH)
Peso: 6 Kg
