SPECIFICATIONS:
LIGHT SOURCE:
• Osram SIRIUS HRI 420W Discharge Lamp
• CRI: 80 +/- 5
• Correlate color temperature: 7,800K +/- 300K
• Full Power (420W) and Eco Mode (330W) operation
• Up to 4,000 Hour Lamp Life (**Test lab conditions. May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
PHOTOMETRIC DATA:
• Lumens: TBA
• Zoom Range: Beam Mode: 1.6°-17° / Spot Mode: 3°-38°
EFFECTS:
• Beam, Spot and Wash
• Motorized Zoom
• Frost Filter
• 2 Prisms on Dual Planes
• CMY/Color Macros
• Gobo/Prism Macros
• Motorized Focus
• High Speed Shutter and Strobe
• Pan Degree: 540°/630°
• Tilt Degree: 270°
COLOR:
• Full CMY Color Mixing System
• White Color Temp Presets
• 12 Position Color Wheel
• 27 Color Macros (Color Wheel + CMY)
GOBOS:
• 2 Gobo Wheels
• 9 Interchangeable-Rotating / Indexing Glass Black & White Gobos
• 14 Static-Stamped Metal Gobos
CONTROL/CONNECTIONS:
• 3 DMX Channel Modes (24, 28 & 32)
• 1 USER Settable DMX Channel Mode
• (4) Button Touch Panel
• Full Color 180° Reversible LCD Menu Display
• DMX & RDM Protocols
• Outdoor, IP66 5-pin DMX In/Out
• Outdoor, IP66 Locking Power In/Out
DIMENSIONS / WEIGHT:
• Length: 290mm
• Width: 430mm
• Height: 743mm
• Weight: 31 kg
ELECTRICAL:
• AC 100-240V 50/60Hz
• 420-Watt Max Power Consumption
• -20°C to 45°C
APPROVALS / RATINGS:
• CE
• cETLus (Pending)
• IP65-Rated
Specifications subject to change. Preliminary Data!
