Different operating modes, Limit (1/2/3/4), FIFO (1/2/3/4), chair only
5 transmission channels with independent volume adjustments
Accepts up to 256 microphones, 5 microphones can be activated at the same time, optional video tracking
Up to 16 complete systems in one place
Band scan and automatic selection of the best frequencies
Automatic microphone
synchronization Selective multi-channel filtering that eliminates interference
Elimination of the Larsen effect and noise Noise
detection circuit with TONE system -LOCK to protect the system from parasitic noise
Automatic extinguishing of the microphones when the receiver is turned off
Symmetrical and asymmetrical audio outputs
Compatible with the automatic tracking function of a video camera
USB recording module to record the debates
Compatible microphones: HTX-28C (Presidency microphone) and HTX-28D (delegate microphone)
Optional accessory: Flight case charger to simultaneously charge 16 batteries
Technical specifications.
Feeding | 12-15Vdc 1A via 110-240V~50/60Hz mains adapter |
Consumption | 7W |
transmission method | UHF Wireless (one way) |
audio channel | 5 (1 chairman, 4 delegates) |
carrier frequency | 610MHz~665MHz |
Modulation | FM |
reception sensitivity | -100dBM |
Audio Gain | ?twenty |
Frequency response | 50Hz-15KHz |
Signal to Noise Ratio | >85dB |
total harmonic distortion | <0.8% |
data channel | 16 |
through band | 422.4MHz ~ 438.4MHz |
transmission consumption | ?6dBm |
Communication speed | 100KBPS |
frequency deviation | <0.002 |
carrier | 100m in optimal conditions, 60m in normal conditions |
Dimensions | 485 x 355 x 85mm |
Weight | 7kg |
