Beyma - 5M15WR408
Replacement diaphragm for SPEAKER...
View larger
More info
Technical specifications
Nominal impedance
8 Ohm
Allowable power
400 W AES
Nominal diameter
380 mm 15 in
Sensitivity
99 dB 1 W @ 1 m @ 2π
Minimum impedance
6.4 ohm
Frequency range
40-4000 Hz
Program power
800 W
Recommended box volume
70/150 l 2.45 / 5.25 ft.³
Coil Diameter
76.2 mm 3 in
BL factor
19.2 N / A
Moving mass
0.091 kg
Winding height
16 mm
Air gap height
8 mm
Maximum displacement pp
30 mm
Thiele & Small parameters
Fs
36 Hz
Re
5.6 ohm
Qms
8.2
What is it
0.31
Qts
0.3
You go
236 l
Cms
215 µm / N
Rms
2.5 kg / s
Efficiency %
3.4
Sd
0.088 m²
Xmax
6.3 mm
you
555 cm³
Le @ 1 kHz
1 mH
Construction details
Depth
162 mm 6.4 in
Net weight
6.1 kg 13.4 lb
Total weight
7.1 kg 15.6 lb
Magnet
Ferrite
