Beyma - 5M18LX60V28
Replacement diaphragm for SPEAKER 18...
-
Defender - 85168GREY
Defender Office ER GREY End Ramp grey...
View larger
More info
Technical specifications
Nominal impedance
8 Ohm
Allowable power
700 W AES
Nominal diameter
460 mm 18 in
Sensitivity
98 dB 1 W @ 1 m
Minimum impedance
6.4 ohm
Frequency range
25-1000 Hz
Program power
1400 W
Recommended box volume
80/250 l / 2.8 / 8.8 ft³
Coil Diameter
100 mm 4 in
BL factor
21.8 N / A
Moving mass
0.215 kg
Winding height
20 mm
Air gap height
10 mm
Maximum displacement pp
58 mm
Thiele & Small parameters
Fs
35 Hz
Re
5.1 ohm
Qms
15.72
What is it
0.5
Qts
0.48
You go
236.52 l
Cms
94.5 µm / N
Rms
3.04 kg / s
Efficiency %
1.91
Sd
0.1320 m²
Xmax
8 mm
you
1056 cm³
Le @ 1 kHz
2.1 mH
Construction details
Depth
198 mm 7.79 in
Net weight
11.7 kg 25.7 lb
Total weight
13.2 kg 29.04 lb
Magnet
Ferrite
