Cameo - TS 200 FC

TS 200 FC

Theater Spot with Fresnel Lens and 200 W 6-in-1 LED in black Housing

1100.75€%19.78 You save 217.75€
883,00 €

Add to wishlist

In Stock

Europe Warehouse: 230

More info

Any DJ, band, event organiser or company who considers it important to have the optimum light output combined with an extensive colour spectrum for their stage, podium or lectern, should take a look at the Cameo TS 200 FC. With its mixture of red, yellow, green, amber, lime and cyan (RGBALC), the Fresnel spotlight is a genuine all-rounder that, thanks to 200 W and full colour, is able to meet the very highest demands in virtually all lighting situations. This is made possible by a light output of 5,500 lm at 3,200 K and a simulated halogen lamp dimmer response - so-called Dim-To-Warm technology (DTW). The Cameo TS 200 FC provides you with an LED engine for light in all its forms. The Fresnel spotlight can also be operated in silent mode, making it an all-rounder for use in theatres, on film sets and at events.

  • Wide application range thanks to RGBALC LED for powerful colours, variably adjustable colour temperatures between 2800 k and 8000 k, and excellent CRI>90 colour reproduction
  • Incredible versatility with continuously variable zoom beam angle (14° to 50°)
  • Outstanding quality on any stage thanks to adjustable refresh rate for flicker-free projection
  • Operation via DMX, RDM, standalone and master/slave
  • Perfect for demanding requirements due to robust metal casing and temperature-controlled fan
  • Fitted with rotating barn door and colour filter frame

Product typeLED Fresnel Spotlight
TypeFresnel Theater Spot with zoom function
Colour spectrumRGBALC
Number of LEDs1
Colour temperature2800 - 8000 K
CRI> 90
LED type200 W
Refresh rate12000 Hz, 1530 Hz, 25000 Hz, 3600 Hz, 650 Hz
Dispersion14 - 50 °
DMX inputXLR 3-pin male, XLR 5-pin male
DMX outputXLR 3-pin female, XLR 5-pin female
DMX colour modesCCT, Direct, HSI
Modes of operationDMX512, Master / Slave mode, Standalone
DMX FunctionsAmber, Blue, CCT, Colour macros, Cyan, Device Settings, Dim to Warm, Dimmer, Dimmer Fine, Green, Hue Saturation, Lime, Red, Silent Mode, strobe, Tint
RDMYes
Strobe flash rate1–20 Hz
Standalone modesCCT, Colour macros, Direct, HSI, Master / Slave mode
ControlsDown, Enter, Mode, Up
IndicatorsLC display
Operating voltage100 V AC - 240 V AC, 50 - 60 Hz
Power consumption200 W
Power connectorBlue and White Power Twist
FuseT3A / 250 V (5 x 20 mm)
Housing materialdie cast metal
Cabinet colourBlack
Coolingtemperature-controlled fan
Relative Humidity< 80 %, not condensing
Operating Temperature0 - 40 °C
Luminous flux5500 (@3200 K) lm
Width320 mm
Height370 mm
Depth310 mm
Weight8 kg
Accessories (included)barndoor, Color Filter Frame

CLTS200FC_Cameo_DMX_Control_Table.pdfCLTS200FC_Cameo_Fixture_Library_Daslight.zipCLTS200FC_Cameo_Fixture_Library_grandMA2.zipCLTS200FC_Cameo_Photometrical_Measurements_EN.pdfCLTS200FC_Cameo_Technical_Drawing.dwgCLTS200FC_Cameo_Technical_Drawing.pdfCLTS200FC_Cameo_Users_Manual_EN_DE_FR_ES_PL_IT.pdf
