Design
Simple user interface
Easy navigation
Large touch screen with an easy to understand and intuitive graphical interface
Indications to the user in the configuration, programming and operation process
Console output capacity
No limit on the number of devices, only by the number of supported universes
User interface
Modeled as a smartphone interface
Intuitive interface that allows simple control of all device attributes
Supports gesture control to zoom and scroll
The remote app is identical to the one on the console screen so you can easily switch between one and the other
Playback Faders
Dedicated Grand Master fader
Section dedicated to Cue Stack Control
10 multi-purpose Cue Stack / Chase faders
MagicQ compatible playbacks
Fixture Faders
Fader for intensity control
Flash button
Fixture, Group and Cue modes
RGB LED shows current mode / status
40 fixture faders
Networking
QuickQ supports DMX output over the network via ArtNet / sACN / Pathport
Color control
A dedicated "color control area" with hue and saturation encoders, and a couple of additional buttons for color control
Select from built-in palettes and libraries using the touch screen
Ports
2 USB ports for loading and saving shows, for optional keyboard and mouse, and for audio input / output
Built-in WIFI port for simple connection of tablets and smartphones
Offline Software
Offline editor available for Windows and Mac
Simple updates
Includes MagicVis viewer
Replicates all QuickQ console software excluding output
Touch screen
| 9.7 "
|
Supported Universes
| 4 |
DMX 5-Pin XLR Outputs
| 3 |
Supported Fixtures
| 2048 |
Fixture Faders
| 40
|
Bump buttons
| Yes
|
Dedicated Color / Saturation Encoders
| Yes
|
Encoders Attribute
| 4 |
Master Faders
| 10 Multiple Function PLaybacks |
Cue Stacks
| Multiple |
Dedicated Home Button
| Yes
|
USB
| 2
|
Net
| Yes
|
External Monitor
| 1920 x 1080 HDMI
|
Audio In / Out
| Yes
|
sACN
| Yes
|
ArtNet
| Yes
|
Pathport
| Yes
|
OSC
| Yes |
MIDI
| Yes |
MIDI Timecode
| Yes |
Types of luminaires supported | LEDs, Dimmers & Movers
|
Dimensions (WxDxH)
| 760 x 350 x 106
|
Weight
| 6.1 kg
|
