More info
Specifications
Conductor drains Ø mm: 0,4
Conductor insulation: PE
Conductor insulation Ø mm: 2,6
Conductor resistance Ohm/m: 138 Ohm/km
Outer insulation: PVC 4,2 Ø in mm
Working temperature: -20~50 °C (min./max.)
Voltage overflash: 30V
Nominal impedance: 75 Ohm
Attenuation:
10 MHz: 0,02270 / 90 MHz: 0,18650 / 100 MHz: 0,19060 / 220 MHz: 0,30640 / 470 MHz: 0,76580 / 770 MHz: 0,96420 / 1000 MHz: 1,6122
