COLUMN SYSTEM Includes subwoofer, column array and pole
Speaker configuration: 10' woofer and 6 x 2.8' tweeters
Simple and intuitive installation thanks to satellite pole with integrated wiring and magnetic lock
EV QuickSmart Mobile App configures, controls and monitors up to 6 Evolve systems
QuickSmartDSP offers high-level processing with single-knob operation and LCD display
DSP Functions: 4 Presets (Music, Live, Speech, Club), Mutli-Band-EQ
5 User Presets
Output Delay
Phantom power
Input level
Master level
Frequency response: 43 - 20,000 Hz @ -3 dB / 37 - 20,000 Hz @ -10 dB
Max. SPL: 122 dB
Opening angle (H x V): 120° x 40°
Power: 1000 W
Crossover frequency: 200 Hz
Subwoofer housing made of 15 mm plywood
Column made of composite
Aluminum pole
Includes transport bag for column and speaker pole
Dust cover optionally available (not included)
Carrying case optionally available (not included)
Short spacer bar optionally available (not included)

Inputs:
6 x XLR/Jack combo connectors
1 x 3.5mm mini jack
1 x Stereo RCA
1 x 1/4" Hi-Z Jack input for instrument
1 x 1/4" Jack pedal input

Outputs:
1 x XLR Mix
1 x XLR Aux

Dimensions / weight:
Subwoofer (H x W x D): 530 x 345 x 471 mm, 20.3 kg
Column (H x W x D): 825 x 102 x 172 mm, 4.7 kg
Pole (H x W x D): 929 x 48.5 x 55mm, 1.25kg
