LD Systems - LDMIX102G3

LDMIX102G3

LD Systems MIX 10 G3 Passive 2-Way Slave Loudspeaker to LD Systems MIX 10 A G3. Price per piece.

296.30€%14.95 You save 44.30€
252,00 €

Add to wishlist

In Stock

Europe Warehouse: 230

More info

  • Passive 2-way loudspeaker
  • Ideal as a slave to MIX 10 A G3
  • 10” custom woofer and 1” Celestion HF driver
  • 200 watts RMS power handling
  • 121 dB maximum SPL
  • Rugged birch ply cabinet
  • Shock-resistant front grill provides maximum speaker protection
  • 36 mm dual-tilt pole receptacle for 0° or 5° orientation
Product type
PA loudspeaker
Type
passive
Low/mid driver dimensions
10 "
Woofer size
254 mm
Woofer magnet
Ferrite
Woofer brand
Custom-made
Woofer voice coil
2 "
Woofer voice coil (mm)
50.8 mm
Horn
CD horn
HF driver dimensions
1 "
HF Driver Size
25.4 mm
HF driver magnet
Ferrite
HF driver brand
Celestion
HF driver voice coil
1 "
HF Driver Voice Coil
25.4 mm
Dispersion (H x V)
80 x 70 °
Load rating (RMS)
200 W
Peak power
400 W
Frequency response
65 - 20.000 Hz
SPL (1W/1m)
95 dB
Max. SPL
121 dB
Impedance
4 Ohm(s)
Protection circuits
HF Driver
Loudspeaker inputs
1
Speaker input connections
Speakon compatible
Cabinet material
16 mm Plywood
Cabinet surface
PA painting
Cabinet construction
vented
Monitor angle
50 °
Width
315 mm
Height
489 mm
Depth
307 mm
Features
dual-tilt flange (0°/5°) , Ergonomic handle
Weight
10,8 kg
