Neutrik - CONECTOR NC 3 FM-C-B 1 View larger

Neutrik - CONECTOR NC 3 FM-C-B

CONECTOR NC 3 FM-C-B

World's first 3 pole unisex XLR cable connector, black

28,00 €

Add to wishlist

In Stock

Europe Warehouse: 192

More info

Features & Benefits

  • World's first unisex XLR
  • 3 pole male and female cable connector in one housing
  • Easy selectable gender - converted by sliding housing back and forth
  • Substitute adapters, ideal as an emergency kit
  • With all benefits of the XLR XX series
  • Branded with unique hologram - guarantees genuine and authentic Neutrik product

Technical Information

Product
TitleNC3FM-C-B
Connection TypeXLR
Genderfemale
Electrical
Capacitance between contacts≤ 4 pF
Contact resistance≤ 3 mΩ
Dielectric strength1.5 kVdc
Insulation resistance> 2 GΩ (initial)
Rated current per contact16 A
Rated voltage<50 V
Mechanical
Cable O.D.3.5 - 8.0 mm
Insertion force≤ 20 N
Withdrawal force≤ 20 N
Lifetime> 1000 mating cycles
Wiresizemax. 2.5 mm²
Wiresizemax. 14 AWG
WiringSolder contacts
Locking deviceLatch lock
Material
BootPolyurethan
Contact plating0.2 µm Au
ContactsBrass (CuZn39Pb3) (male)
InsertPolyamdie (PA 6.6 30 % GR)
Locking elementZinc diecast (ZnAl4Cu1) / Ck 67 (spring)
ShellBlack chromium
Shell platingNickel
Strain reliefPolyacetal (POM)
Environmental
FlammabilityUL 94 HB
Standard complianceIEC 61076-2-103
Protection classIP 40
SolderabilityComplies with IEC 68-2-20
Temperature range-30 °C to +80 °C
