Become a singstar - mixer for microphone an line sourcesThe perfect tool for your karaoke party: With the Omnitronic EM-260B Entertainment Mixer you mix 3 microphone and 3 line sources to one stereo output - in an very simple way. Installing the mixer is easy as well, thanks to the small dimensions you are flexible.Design clearly arrangedEven if you are a beginner, you can operate the mixer very easily. As it is clearly structured, you won't get lost. Each channel has a clip LED. The microphone inputs show optional 12 V phantom power. The unit is perfectly suited for bar, restaurant or club house installation.Effects an recording sessionsWith the FX send/return (with FX level control) you can cut in effects to support your voice. Record singing sessions by using the record output.
6-channel microphone line mixer, black
- 6 inputs (3 x mic/line and 3 x line) for mixing to 1 stereo output
- Ideal e.g. for karaoke when microphones need to mixed with CDs
- 3 mono input channels mic/line (XLR, bal.), switchable
- 3 stereo line input channels (RCA)
- Clip LED for each microphone channel
- Each microphone input with optional 12 V phantom power
- FX send/return with FX level control
- Stereo master out (6.3 mm jack) with 2-band equalizer (highs and lows) and level control
- Stereo record output (RCA)
- Rack installation, 1 U
- Housing design: (19") 48,3 cm rack installation
- Master equalizer: 1 x 2 band tone control Stereo
- Height unit: 1 U
- Power connection: Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) (provided)
Inputs MIC 1-3: | XLR |
Max. input level: | -14 dB |
Inputs LINE 1-3: | stereo RCA |
Max. input level: | 24 dB |
RETURN: | 6.3 mm stereo jack |
Outputs: | |
MASTER: | 6.3 mm stereo jack |
REC: | stereo RCA |
SEND: | 6.3 mm jack |
Tone control: | |
High: | -12 dB to +12 dB/ 10 kHz |
Bass: | -12 dB to +12 dB/ 100 Hz |
S/N ratio: | 69 dB |
Distortion: | 0.025 % |
Dimensions (W x D x H): | 482 x 123 x 43 mm (19", 1 U) |
Weight: | 2,2 kg |
Power consumption: | 35,00 W |
Frequency range: | 20 - 20000 Hz |
Height: | 4,45 cm |
Depth: | 12,3 cm |
Width: | 48,3 cm |
Power connection: | Mains Input Socket (M) IEC connector (M) mounting version Power supply cord with safety plug (M) |
Power supply: | 115/230 V AC, 50/60 Hz |
