Omnitronic - WS-1RA 2.4GHz Receiver, active

WS-1RA 2.4GHz Receiver, active

WS-1RA 2.4GHz Receiver, active

In Stock

Europe Warehouse: 70

More info



Digital audio transmission system 2.4 GHz, 2 x 20 watts/4 ohms

  • Active, digital wireless receiver for reception of stereo audio signals with 2.4 GHz
  • Transmit music via radio from your PC or MP3 player anywhere in your home with outstanding audio quality
  • Simultaneous operation of an unlimited number of receivers possible
  • Amplifier power 2 x 20 watts/4 ohms
  • 2 clamp terminals for passive speakers
  • RCA output L/R for connecting stereos or active speakers
  • Digital transmission in the 2.4 GHz range provides for high resistance to interference and unique sound quality (16 bits/48 kHz)
  • Operating range up to 30 m indoors and up to 50 m outdoors
  • Volume control
  • Push button for pairing with the transmitter
  • Removable rod antenna
  • Operation via supplied power unit
  • Rugged, compact metal housing
  • 2.4 GHz ISM band - license-free worldwide


Power supply:100-240 V AC, 50/60 Hz
via power unit included in the delivery
Carrier frequency:2406-2472 MHz (ISM), 32 channels
Modulation:GFSK
Coverage:30 m (in buildings), 50 m (in the open air)
Frequency range:20-20000 Hz
S/N ratio:96 dB
THD:-70 dB
Crosstalk:-96 dB
Line output:RCA L/R
Speaker outputs:clamps L/R
Converter:16 bits
Sample rate:48 kHz
Dimensions (LxWxD):145 x 120 x 70 mm
Weight:500 g
