11039486 OMNITRONIC PAS-151 MK3 Subwoofer

Passive 15" bassreflex subwoofer with 700 W RMS, 8 ohms

• Rugged Pro PA subwoofer, qualified for suspension
• 38 cm (15") bass speaker
• Parallel Speaker connectors
• Rugged multiplex cabinet
• Scratch-resistant lacquer surface
• Recessed aluminum handlebars
• Impact-resistant steel grille with acoustic foam
• Flange for mounting top speakers
• Threaded inserts for suspended installation
• Transport aid: Wheels optional

11039478 OMNITRONIC PAS-212 MK3 2-Way Top

Passive speaker with 12" woofer, 1" driver and 300 W RMS

• Rugged full-range top speaker, qualified for suspension
• Trapezoidal, multi-functional multiplex cabinet with scratch-resistant lacquer surface
• 2-way bass-reflex system with 30 cm woofer (8 cm voice coil)
• 2.5 cm compression driver with ferrite magnet (3.8 cm voice coil with polymer diaphragm)
• Parallel Speaker connections
• Optimized for combination with PAS subwoofers
• Dual flange with 0° and 5° tilt angle enables flexible positioning
• M8 threaded inserts for suspended installation
• Protective grille and recessed aluminum handlebars
• Applications: standing, on a subwoofer or speaker stand, suspended

60004559 OMNITRONIC Distance Tube Subwoofer/Satellite with Crank

Variable distance tube (M20 thread), height adjustable via crank 80-110 cm

• Connecting tube for satellite systems
• Height adjustable via crank 80-110 cm
• M20 thread
• Powder-coated steel version
• Color: black

10451635 OMNITRONIC XDA-1002 Class D Amplifier

Stereo PA amplifier with SMPS, 2 x 510 W / 4 ohms, 2 x 300 W / 8 ohms

• Stereo PA amplifier with class D circuitry
• Low weight and height due to integrated switch mode power supply
• Speaker switch-on delay and auto limiters
• 2 operating modes can be selected (stereo or bridged)
• 2 level controls
• LEDs for activated protective circuit, limiter, signal, and power
• Complete protection set against short-circuit, overheat, DC voltage, power on/off transients, soft start
• Ground lift switch against humming
• Fan cooling
• Electronically balanced inputs via XLR mounting jacks with feed-through output
• Speaker outputs via lockable speaker jacks
• Housing design: (19") 48.3 cm rack installation 1 U

10451636 OMNITRONIC XDA-2402 Class D Amplifier

Stereo PA amplifier with SMPS, 2 x 1200 W / 4 ohms, 2 x 880 W / 8 ohms

• Stereo PA amplifier with class D circuitry
• Low weight and height due to integrated switch mode power supply
• Speaker switch-on delay and auto limiters
• 2 level controls
• LEDs for activated protective circuit, limiter, signal, and power
• Complete protection set against short-circuit, overheat, DC voltage, power on/off transients, soft start
• Ground lift switch against humming
• Fan cooling
• Electronically balanced inputs via XLR mounting jacks with feed-through output
• Speaker outputs via lockable speaker jacks
• Housing design: (19") 48.3 cm rack installation 1 U

10356321 OMNITRONIC DXO-24E Digital Controller

Digital stereo active crossover with 2 inputs and 4 outputs, incl. software

• Flexible routing configurations for all standard mono and stereo output operating modes
• 2 analog inputs and 4 analog outputs (XLR)
• Active frequency filter types (Bessel, Butterworth and Linkwitz-Riley) with slopes up to 24 dB/octave split up the audio signal into different frequency bands
• Incl. software editor (for PC and Mac) for remote control via computer through USB interface: store, transfer, and manage your presets
• Up to 30 user presets storable in the device via software
• Alphanumeric LCD screen with 2 lines of 16 characters each
• Input sensitivity digitally adjustable
• Inputs and outputs with 4-digit LED level meter as well as clip and limit LED indicator
• Mute switch with LED indicator per output
• 7-band parametric EQ per output
• Up to 7 ms signal delay adjustable for the outputs
• Output limiter with adjustable limits and automatic attack and release settings as overload protection for your amplifying system
• Switchable phase
• Lock function for protecting the program settings
• Windows XP, Vista, 7, 10 and Mac OS X 10.5.8 and better
• DSP: Digital signal processor
• PC connect: DXO Software via USB Firmware can be updated
• Housing design: (19") 48.3 cm rack installation 1 U

30109784 ROADINGER Amplifier Rack PR-2, 4U, 47cm deep

Flightcase for 483 mm units (19")

• Profile rails with 4 U mounting facility for 483 mm units (19"), e.g. PA amplifiers, power packs, additional equipment
• Front and rear rack rails
• 2 removable covers (double-door version)
• Max. depth 420 mm (plus 90 mm per cover)
• High-quality workmanship with plywood multilayered glued, black laminated
• Aluminum profile frames (30 mm) with rounded edges
• Three-leg, medium-sized steel ball corners
• 4 high-quality butterfly locks (w/o locking function)
• 2 wooden slide rails on the bottom
• 2 hinged, chrome case handles
• Delivery includes mounting screws
• Available in different height units (1 U = 44 mm)
• Housing design: 4 U

30227912 PSSO Speaker cable Speakon 2x2.5 10m bk

High-quality speaker cable

• With Neutrik plugs from Liechtenstein
• Cable from German production
• 2 pole speaker cable
• With Neutrik Speakon cable plugs
• Cable cross-section: 2.5 mm²
• Cable length: 10 m
• Cable diameter: 8 mm
• Weight: 1 kg

30227840 PSSO XLR cable 3pin 1m bk Neutrik

Dependable microphone cable

• High quality connection for microphones etc.
• High conductivity
• Slim and short construction
• Made in Germany
