Active crossover, stereo 3-way operation
- 3-way stereo operation
- Variable 24 dB per octave Linkwitz-Riley filters
- Individual output level controls for each frequency range
- Continuously adjustable crossover frequencies low/mid and mid/high
- Individual muting for input signal and each frequency range
- CD horn EQ for smoother treble selectable
- Switchable low and mid phase
- Input level adjustable
- Balanced XLR inputs and outputs
- Housing design: (19") 48.3 cm rack installation 1 U
| Power supply: | 230 V AC, 50 Hz |
| Power consumption: | 14 W |
| Power connection: | Mains input IEC connector (M) mounting version Power supply cord with safety plug (provided) |
| S/N ratio: | >100 dB |
| Crossover frequency: | mid/high 800-9200 Hz |
| low/mid 80-920 Hz | |
| Housing design: | (19") 48.3 cm rack installation 1 U |
| Width: | 48,3 cm |
| Height: | 4,45 cm |
| Depth: | 18,7 cm |
| Weight: | 2,37 kg |
| Operation modes: | 3-way stereo |
| Inputs: | XLR, electronically balanced/unbalanced |
| Impedance: | balanced >50 kohms, unbalanced >25 kohms |
| Max. input level: | +22 dBu typical, balanced or unbalanced |
| Outputs: | XLR, electronically balanced/unbalanced |
| Impedance: | balanced 200 ohms, unbalanced 100 ohms |
| Max. output level: | >+21 dBu balanced/unbalanced into 2 kohms or greater |
| THD: | 0.05% |
| Crosstalk: | >80 dB, -3 dB |
| Filter type: | Linkwitz-Riley, 24 dB/octave, state-variable |
| Phase invert: | low/mid output |
| Input gain: | - ~ to +6 dB |
| Output gain: | - ~ to +0 dB |
