UHF True Diversity Technology to Avert Interferences

Features

• 240 Preset Channels for each microphone
• IR Matching System for Quick Setup
• 630-660MHz UHF Band
• Simple and Outright User Interface
• LCD display on Transmitters and TFT color displays on Receiver
• Digital Pilot Technology to allow up to 200 systems operation simultaneously without interferences
• Transmitter AF-level and Battery-Low Monitoring directly on the Receiver
• Automatic mute function on microphones
• 80m Ideal Distance (without obstacles)
• Professional Hand held Microphone with Dynamic Cardioid Capsule
• 19 Rack-Mount adapter kit included

Specs

• http//www.soundsationmusic.com/
• Carrier Frequency: UHF630-660MHz
• Frequency Stabilization: < 30ppm
• Dynamic Range: >100dB
• Total Harmonic Distortion: <0.5%
• Frequency Response: 40Hz-15KHz 3dB
• Audio Output Level: Balanced 400mV; Unbalanced 400mV
• Packing Dimensions (WxHxD): 473 x 75 x 408 mm
• Packing Gross Weight: 3.4 kg
• Receiver Power Supply: DC 13.5V / 1.5A
• Receiver Power Consumption: 5W
• Signal/Noise Ratio: >95dB
• Receiving Sensitivity: 5dBuV
• De-Emphasis: 50uS
• Receiver Size (WxHxD): 420 x 50 x 220 mm (antennas not incl.)
• Antenna: 255 mm (not bent)
• Receiver Net Weight: 2.02 kg
• Transmitter Power: 10mW(Max)
• Modulation Type: FM
• Max Deviation: 25KHz
• Transmitter Battery Voltage: 3V (2x1.5V AA Battery)
• Continuous Using: 5 hours
• Hand-held Mic. Size (W/DxH): 35 (min) - 53 (max) x 260 mm
• Hand-held Mic. Net Weight: 0.335 kg (batteries included)
