850mW RGB graphic laser (200mW R, 150mW G, 500mW B) for complete color palette effects

Features

• 20K scanner speed
• Built-in Fish-eye Lens for 180 emitting radiation Angle
• Lens Magnification: 0.23X
• 3-dimensional adjustment frame for maximum alignment of laser emitters
• Built-in 2 sets of programs and 2 sets of voice programs
• SD-Card reader for quick access to external ILDA libraries
• ILDA standard protocol for maximum compatibility with other ILDA software/hardware equipment
• Operation Modes: ILDA show in SD Card playing, Internal Program playing, Sound, DMX, Master/Slave
• DMX: 24CH mode
• 128x64 dot multi-function LCD display system fox quick access to all parameters memory content
• Job wheel with switch for easy menu navigation and editing
• Wired Remote Control Connector for hard-blackout
• Key switch and safety eye for maximum safety of use and installation

Specs

• http://www.soundsationmusic.com/
• Laser Red: 638nm/200mw
• Laser Green: DPSS 532nm/150mw
• Laser Blue: 450nm/500mw
• Laser Type: Class 4 Laser
• Zoom angle: 1-36
• Scanner Speed: 20K
• I/O Connectors: (DMX) 3-pin XLR / (ILDA) DB25
• S/D Connectors: Outlay SD card store programs
• DMX: 24CH
• Maximum External Temp: 104F (40C)
• Cooling System: Green TEC cooling
• Power Supply Type: Switching (internal)
• Power Range: 100-240V 50/60Hz
• Consumption: 30W
• Fuse: T1.6A 250V
• Unit Dimension (LxHxD): 316x89x154 mm
• Unit Net Weight: 4.26 kg
• Packing Size (LxHxD): 406x194x326 mm
• Packing Weight: 5kg
