UHF True Diversity Technology to Avert Interferences

Features

• 300 Preset Frequencies and IR Matching System for Quick Setup
• 823-832MHz UHF Band
• Simple and Outright User Interface with LCD display on Transmitter and Receiver
• Digital Pilot Technology to allow Multi-system Operation
• Transmitter AF-level and Battery-Low Monitoring directly on the Receiver
• 80m Ideal Distance (without obstacles)
• Bodypack with Connector Locking System
• Professional and Lightweight Headset with High-Sensibility Dynamic Cardioid Capsule
• Half 19 Rack Unit with Rack-Mount Kit (optional)

Specs

• http://www.soundsationmusic.com/
• SYSTEM
• Carrier Frequency: UHF823-832MHz
• Frequency Stabilization: < 30ppm
• Dynamic Range: >90dB
• Total Harmonic Distortion: <0.5%
• Frequency Response: 40Hz-15KHz 3dB
• Audio Output Level: Balanced 400mV; Unbalanced 400mV
• Packing Dimensions (WxHxD): 435 x 104 x 321 mm
• Packing Gross Weight: 2.5 kg
• RECEIVER
• Power Supply: DC 17V / 300mA
• Consume Power: 5W
• Signal/Noise Ratio: >90dB
• Receiving Sensitivity: 5dBuV
• De-Emphasis: 75uS
• Dimensions (WxHxD): 210 x 43 x 187 mm (antennas not included)
• Antenna: 255 mm (not bent)
• Net Weight: 0.53 kg
• POCKET TRANSMITTERS
• Transmitter Power: 10mW (Max)
• Modulation Type: FM
• Max Deviation: 25KHz
• Spurious Emission: >40dB
• Battery Voltage: 3V (2x1.5V AA Batteries)
• Continuous Using: 5 hours
• Dimensions (WxHxD): 62 x 103 x 30 mm
• Antenna (W/DxH): 3 x 9 mm
• Net Weight: 0.132 kg (batteries included)
