UNIVERSAL DMX is a collaboration between Sunlite and Tritón Blue to offer a product of the highest quality and tested worldwide for the control of DMX systems. Total library and software compatibility for all products.
Technical specifications
General
Dimensions: 77 x 87 x 40mm
Weight: 120g
USB connection: Yes
WIFI connection: Yes
ESA2 software: PC / Mac
ESA pro 2 software: PC / Mac
DMX channels: 512 (expandable to 1024 with SUT technology)
standing alone
Number of scenes: 99
Number of zones: 1
Independent memory: 100k
Memory capacity (20 channels): 3935 steps
Memory capacity (60 channels): 1550 steps
Memory capacity (512 channels): 190 steps
Supply voltage: 5-5.5 V DC
Power Connector: USB Type-C
Hardware
Mechanical buttons: 3
Internal connector: HE10
Port Triggers: 8
Clock / Calendar Triggers - Available in 2020
Smartphone / tablet control: Yes
Package content
Interface SLESA-U10
USB Cable
compatible software
Description for projects, contests and tenders
Universal DMX controller SLESA-U10 with RDM of 512 DMX channels, built-in WIFI connection. 99 scenes, 1 zone, 100K independent memory. Power supply 5-5.5 V DC, Dimensions: 77 x 87 x 40 mm. Weight: 120g. Compatible with ESA2 and ESA PRO2 Software.
