Specifications:

• Throat diameter 36 mm. 1.4 in.
• Rated impedance 8 ohms
• Minimum impedance 7.3 ohms @ 3.5 kHz
• D.C. Resistance 5.5 ohms
• Power capacity 70 w AES above 0.8 kHz
• 90 w AES above 1.5 kHz
• Program power 140 w above 0.8 kHz
• 180 w above 1.5 kHz
• Sensitivity 110 dB 1 w @ 1m coupled to TD-565 horn
• Frequency range 0.6 - 20 kHz
• Recommended crossover 800 Hz or higher (12 dB/oct. min.)
• Voice coil diameter 72.2 mm. 2.87 in.
• Magnetic assembly weight 6.5 kg. 14.33 lb.
• Flux density 1.875 T
• BL factor 10 N/A
