Specifications:

• Throat diameter 36 mm. 1.4 in.
• Rated impedance 8 ohms.
• Minimum impedance 7.2 ohms @ 3 kHz
• D.C. Resistance 5.5 ohms.
• Power capacity * 70 w AES above 1 kHz
• Program power 140 w above 1 kHz
• Sensitivity ** 108 dB 1 w @ 1m coupled to TD-385 horn
• Frequency range 0.6 - 20 kHz
• Recommended crossover 0.8 kHz or higher (12 dB/oct. min.)
• Voice coil diameter 72.2 mm. 2.84 in.
• Magnetic assembly weight 2.1 kg. 4.62 lb.
• Flux density 2 T
• BL factor 1 N/A
