They can be found at almost every event - large or small, on live stages or corporate events, in the theatre or TV studio. LED PAR spotlights are permanent fixtures in the portfolio of every lighting designer and rental provider - and they have to meet the highest demands in terms of lighting quality, operation and flexible use.
With the second generation of the STUDIO PAR series, Cameo has revised the genre of classic LED PAR fixtures for static lighting on all levels and given the design an unmistakable facelift.
The extremely compact STUDIO PAR 4 G2 is based on 12 x 8 W 4-in-1 RGBW LEDs with an impressive luminous flux of 4,100 lm at a 16° beam angle and uniform light distribution. Thanks to the adjustable PWM frequency in the range from 650 Hz to 25 kHz, the STUDIO PAR 4 G2 is also suitable for flicker-free operation in theatres, TV studios, on film sets or at indoor light art festivals. Even more versatile is the use in combination with the optionally available Cameo iDMX Stick to control the STUDIO PAR 4 G2 wirelessly via W-DMX™.
For particularly flexible mounting, the STUDIO PAR 4 G2 can be optionally retrofitted with a fold-out 16 mm TV spigot based on patented SPIN16® technology.
Product type | LED PAR Lighting |
Type | Studio PAR |
Colour spectrum | RGBW |
Number of LEDs | 12 |
LED type | 4in1 RGBW 8 W SMD LED |
Luminous flux | 4700 lm |
Dispersion | Beam Angle: 19 ° |
Dispersion | Field Angle: 27 ° |
Lens | 12 x acrylic lens |
LED PWM Frequency | 650 Hz, 1530 Hz, 3600 Hz, 12000 Hz, 18900 Hz, 25000 Hz |
Dimmer resolution | 16 bit |
Dimmer curves | Exponetial |
Dimmer curves | Linear |
Dimmer curves | Logarithmic |
Dimmer curves | Square |
Strobe | 0 - 20 Hz |
CRI | >72 Ra |
DMX input | 3-Pol |
DMX input | iDMX slot |
DMX output | 3-Pol |
DMX mode | 10-channel |
DMX mode | 14-channel |
DMX mode | 1-channel |
DMX mode | 3-channel |
DMX mode | 4-channel |
DMX mode | 6-channel |
DMX mode | 8-channel |
DMX Functions | colour macro |
DMX Functions | Device Settings |
DMX Functions | Dimmer |
DMX Functions | Dimmer Curve |
DMX Functions | EZ-Chase |
DMX Functions | RGBW |
DMX Functions | strobe |
Standalone modes | Auto Mode |
Standalone modes | Static |
System settings | Calibration |
System settings | Default settings |
System settings | Dimmer |
System settings | Dimmer Response |
System settings | Display |
System settings | Fan mode |
System settings | LED PWM Frequency |
System settings | Signal Fail |
System settings | Wireless |
Controls | 4 x Buttons |
Controls | Down |
Controls | Enter |
Controls | menu |
Controls | Up |
Indicators | OLED Display |
Relative Humidity | < 80 %, not condensing |
Protection class IP | IP20 |
Ambient temperature (operating) | -10 - 40 °C |
Cooling | Convection |
Cooling | low-noise fan |
Operating voltage | 100 V AC - 240 V AC, 50 - 60 Hz |
Power connector | PowerCon Blue I/O |
Fuse | T2A |
Max. Power consumption | 90 W |
Housing | Die-cast aluminium |
Cabinet surface | Powder coated |
Cabinet colour | Black |
Height | 360 mm |
Width | 310 mm |
Depth | 250 mm |
Weight | 5,1 kg |
