STUDIO PAR TW G2
They can be found at almost every event - large or small, on live stages or corporate events, in the theatre or TV studio. LED PAR spotlights are permanent fixtures in the portfolio of every lighting designer and rental provider - and they have to meet the highest demands in terms of lighting quality, operation and flexible use.
With the second generation of the STUDIO PAR series, Cameo has revised the genre of classic LED PAR fixtures for static lighting on all levels and given the design an unmistakable facelift.
The extremely compact STUDIO PAR TW G2 is based on 12 x 10 W 3-in-1 Tunable White LEDs with an impressive luminous flux of 4,150 lm at an 18° beam angle and uniform light distribution. Thanks to its infinitely variable white light adjustment in the range from 2,800 to 6,800 K, variable PWM frequency (650 Hz to 25 kHz) and natural colour rendering (CRI>96), the STUDIO PAR TW G2 is also suitable for use in theatres, TV studios, on film sets or at indoor light art festivals. Even more versatile is its use in combination with the optionally available Cameo iDMX Stick to control the STUDIO PAR TW G2 wirelessly via W-DMX™.
For particularly flexible mounting, the STUDIO PAR TW G2 can be optionally retrofitted with a fold-out 16 mm TV spigot based on patented SPIN16® technology.
Product type | LED PAR Lighting |
Type | Studio PAR |
Colour spectrum | Tunable White |
Colour spectrum | Warm White/Cold White |
Number of LEDs | 12 |
LED type | 3in1 WW/CW/A 10 W SMD LED |
Color temperature | 2800 - 6800 K |
Luminous flux | 4150 lm |
Dispersion | Beam Angle: 18 ° |
Dispersion | Field Angle: 35 ° |
Lens | 12 x acrylic lens |
LED PWM Frequency | 650 Hz, 1530 Hz, 3600 Hz, 12000 Hz, 18900 Hz, 25000 Hz |
Dimmer resolution | 16 bit |
Dimmer curves | Exponetial |
Dimmer curves | Linear |
Dimmer curves | Logarithmic |
Dimmer curves | Square |
Strobe | 0 - 20 Hz |
CRI | >95 Ra |
DMX input | 3-Pol |
DMX input | iDMX slot |
DMX output | 3-Pol |
DMX mode | 11-channel |
DMX mode | 1-channel |
DMX mode | 2-channel |
DMX mode | 3-channel |
DMX mode | 4-channel |
DMX mode | 5-channel |
DMX mode | 8-channel |
DMX Functions | CW |
DMX Functions | Device Settings |
DMX Functions | Dimmer |
DMX Functions | Dimmer Curve |
DMX Functions | EZ-Chase |
DMX Functions | strobe |
DMX Functions | WW |
Standalone modes | Auto Mode |
Standalone modes | Static |
System settings | Default settings |
System settings | Dimmer |
System settings | Dimmer Response |
System settings | Display |
System settings | Fan mode |
System settings | LED PWM Frequency |
System settings | Signal Fail |
System settings | Wireless |
Controls | 4 x Buttons |
Controls | Down |
Controls | Enter |
Controls | menu |
Controls | Up |
Indicators | OLED Display |
Relative Humidity | < 80 %, not condensing |
Protection class IP | IP20 |
Ambient temperature (operating) | -10 - 40 °C |
Cooling | Convection |
Cooling | low-noise fan |
Operating voltage | 100 V AC - 240 V AC, 50 - 60 Hz |
Power connector | PowerCon Blue I/O |
Fuse | T2A |
Max. Power consumption | 115 W |
Housing | Die-cast aluminium |
Cabinet surface | Powder coated |
Cabinet colour | Black |
Height | 360 mm |
Width | 310 mm |
Depth | 250 mm |
Weight | 5,1 kg |
