Palmer Pro - PAN16
Palmer Pro PAN 16 19" DI Box 8...
-
Gravity - TMS 4321 B
Touring series Tripod Mic Stand...
More info
- 19“ passive DI-Box
- 8 Channels
- Up to 16 Inputs
- Link Merge Function
- Flexible PAD: -10dB, -20dB, -30dB
- Transformer balanced and isolated outputs
Product type
DI Boxes
Type
passive
Channels
8
Inputs
8 / 16
Input connectors
6.3 mm jack
Max. input level
+ 54 dBu
Input impedance
(@ 60 Hz) 1 M Ohm(s)
Input pad
0 / -30 dB
Outputs
4 (+ 4 Parallel Thru out)
THRU outputs/channel
2
Output connectors
6.3 mm jack , XLR
Max. output level
+4 dBu
Output impedance
600 Ohm(s)
Frequency response
10 - 40000 Hz
Transformer balanced
Yes
Ratio
10 : 1
Controls
ground lift , merge , PAD -10dB , PAD -20dB
Cabinet material
sheet steel
Cabinet surface
Powder coated
Width
480 mm
Width
19 "
Depth
200 mm
Height
45 mm
Height
1 U
Weight
2,39 kg
Reviews
No customer comments for the moment.
