View larger | Departure | |
|---|---|
| Lux @ 5m | 5500 (12 °) |
| Beam angle | 12 ° -17 ° (manual) |
| Light source | 100W white LED |
| Electric | |
| Input voltage | 100 ~ 240VAC, 50 / 60Hz (auto range) |
| Energy consumption | 360 W max |
| Control | |
| On board | Full color display |
| Control protocol | DMX512, Automatic, Sound, Manual, Master-Slave |
| Control Personality | Advanced 14 channels / Basic 10 channels |
| Optical system | |
| Intensity regulator | 0-100% |
| Strobe light | 0-20Hz |
| Attention | Motorized |
| Prism | 6-facet circular and 5-facet linear rotary prism |
| Movement | |
| Bread | 540 ° |
| Inclination | 270 ° |
| Pan / Tilt Resolution | 16 bit |
| Special | Pan / Tilt Motion Blackout, User Selectable Pan & Tilt Ranges, 540 ° / 360 ° / 180 °, Pan / Tilt Reverse Motion |
| Gobos and colors | |
| Rotating wheel | 7 gobos |
| Gobo functions | Gobo flow effect, gobo smoothie |
| Rotation | Bidirectional |
| Color wheel | 8 dichroic filters + white |
| Color functions | Divided colors, Rainbow-flow effect |
| Physical | |
| Color | Black |
| accommodation | Fire retardant metal and plastic |
| Data connection | XLR 3p input and output |
| Electric connection | Pro Power input and output |
| Dimensions (WxDxH) | 325 x 210 x 420 mm |
| Weight | 11.3 kilograms |
| Certification and security | |
| Certification | EC |
| Max. Room temperature. | 40 ° C |
